Technical Specifications
The UV-5R Mini maintains the powerful performance of the classic model while upgrading the convenience factor. Here are the core specifications:
| Frequency Range |
VHF: 136-174MHz | UHF: 400-480MHz |
| Channel Capacity |
128 Memory Channels |
| Output Power |
Selectable High/Low Power Settings |
| Battery & Charging |
7.4V Li-ion Battery via USB Type-C |
| Programming Method |
Bluetooth App Programming (Smartphone) or PC CPS Software |
| Special Functions |
One Key Frequency Copy, CTCSS/DCS, FM Radio, LED Flashlight |
| Antenna Impedance |
50Ω |
What's in the Box?
Each Baofeng UV-5R Mini comes fully equipped with everything you need to start communicating right away. (Note: If you purchase the Twin-Pack option, you will receive two of each item listed below).
- ✅ Baofeng UV-5R Mini Radio Body
- ✅ Li-ion Battery Pack (with Type-C Port)
- ✅ High-Gain Antenna
- ✅ Earpiece & Belt Clip
- ✅ USB Type-C Charging Cable
- ✅ Wrist Strap & User Manual
Downloads & Programming Guides
Take full control of your dual-band radio. Whether you prefer using the modern smartphone app or traditional PC software, we have the resources you need:
Frequently Asked Questions (FAQ)
Q1: Is the UV-5R Mini a license-free PMR446 radio in the UK?
No, it is not a license-free PMR446 radio. The UV-5R Mini outputs significantly more power than the 0.5W legal limit for license-free radios. To legally transmit on amateur radio frequencies in the UK, you must hold a valid Ofcom license. However, anyone can purchase the radio and use it for scanning/receiving non-restricted frequencies.
Q2: What is the realistic range of the UV-5R Mini in the UK?
Range is heavily dependent on your environment. In open, unobstructed UK landscapes like the Lake District or Scottish Highlands, you can achieve several miles of clear communication. In dense urban areas like London or thick forests, the range will naturally decrease due to physical barriers blocking the VHF/UHF signals.
Q3: How does Bluetooth app programming work?
It is incredibly simple and completely wire-free. Download the dedicated app on your iOS or Android smartphone, pair it with your UV-5R Mini via Bluetooth, and you can instantly edit channels, frequencies, and CTCSS/DCS privacy codes directly from your phone screen. See our full guide linked above.
Q4: Can I charge the UV-5R Mini with my phone charger?
Yes! This is a massive upgrade over older models. The UV-5R Mini features a universal USB Type-C port directly on the battery. You can use standard Type-C cables connected to wall adapters, car chargers, laptops, or portable power banks.
Q5: What does the "Wireless Frequency Copy" feature do?
This feature is perfect for group coordination. If someone in your team has a different radio transmitting on a specific frequency, the UV-5R Mini can detect and clone that exact frequency wirelessly with a single button press, allowing you to join their conversation instantly.
Q6: Does the UV-5R Mini use the same accessories as the classic UV-5R?
Yes, it does. The UV-5R Mini retains the industry-standard Kenwood K-plug (2-pin) connector. This means if you have existing Baofeng speaker mics, earpieces, or programming cables from a classic UV-5R, they will work perfectly with the Mini.
